In our chemistry and materials laboratories, we have instrumentation to carry out chemical analysis, material characterisation, and material processing.
- Thermal properties
- DSC, DMA, TGA
- Rheology and flow dynamics
- Rheometer, capillary rheometer
- Material characterisation
- FTIR, SEM-EDX, GC-MS, HPLC, SEC
- Instruments for trace analysis
- GC-MS, GC-FID, ICP, IC
- Corrosion testing facilities
- Aging and compatibility test facilities
- Microscopy
- LOM, Digital LOM, SEM
- Material processing
- rolling mill, hot press, extruder, micro-compounder
- Fire resistance testing
- Cone calorimeter
- Washdown test rig to mimic washing cycles with different chemicals
Our mechanics laboratory naturally features standard mechanical testing equipment, as well as special purpose test rigs designed by us according to customer specified needs.
- Component mechanical testing
- Hydraulic testing machines from 25 to 1000 kN
- Hydraulic testing machines equipped with strong floor
- Universal testing Machines 100 kN
- Climate test chamber: temperature range: -60⁰C ~ +250 ⁰C, Humidity: 10% ~ 95% RH
- Testing rig for friction and wear
- Testing rig for full scale fatigue testing of power cables and flexible tubular structure.
In our virtual laboratory we have access to both leading commercial software and in-house developed code for:
- Structural simulation
- Computational fluid dynamics (CFD)
- Multiphysics simulation
- Electro-magnetics
- Acoustic
- Molecular Dynamic
- Density Functional Theory
- AI and machine learning
- Electro-thermal simulation
- Charge transport modelling
In our electrical testing laboratories (from low to high-voltage) we have capabilities to perform component and system testing, development of new measurement methods and non-standard tests such as:
- AC or DC testing
- Electrical breakdown test
- Endurance test
- Electro-thermal aging test
- Partial discharges (PD) measurements
- Lightning impulse and switching impulse tests
- Electrical type test
- Dielectric and leakage current tests
We also have the equipment and competence to perform electrical material characterisations, such as:
- DC conductivity
- Dielectric loss (tanDelta)
- Permittivity
- Electric breakdown
- Volume and surface resistivity
Key equipment available in the electric laboratories includes:
- Partial Discharge (PD) measurements (noise level < 1 pC)
- AC transformer 200 kV / 15A
- DC generators up to 750kV / 5mA
- AC transformers up to 600kV / 1A
- Impulse generator: 2000 kV
- Current heating up to 2300 A
- Space charge measurements - PEA
- Capacitance / dielectric loss measurements up to 1.1µF
- TanD measurement system
- Large oven for long-term testing
- Dimension: (Width, depth, height) 4x3.4x3.2 m; Temperature range: 0 °C to 250 °C
- Ultra high-speed cameras
- SF6 gas capability
- Tank for testing in oil
